Kura Top X5
Available colors

Kura Top X5

Suitable for indoor and outdoor ceiling installations.
Die-cast aluminium body EN-AB44100, technopolymer fixing bracket.
Silk-screened tempered glass diffuser. Polycarbonate reflectors.
Silicone gaskets to maintain IP 65 rating.
A4 stainless steel hardware. Latest generation LED CRI > 95.
LL codes: direct power supply 220-240V.
LZ codes: power supply excluded.
4000K (N), 3000K (3) and 2700K (2) LED.
No photobiological risk, RG0 risk group exempt (EN62471).
IP 65
Outdoor e waterproof
Sea Treatment
Sea Treatment
CRI 95
CRI 95
Years warranty on LED circuit
Years warranty on LED circuit
Diffuser
Serigraphed glass
Kura Top X5
  • IP 65
  • IK 06 1J xx3
  • CE
LED
W LM REAL LM COL. GLASS
CODE
Download
12,5 900 785
CL.I LED version with integrated ballast 220-240 V
White RAL 9003
LL14706W
Light Grey RAL 7044
LL14706L
Dark Grey RAL 7021
LL14706D
Corten
LL14706K
10 900 785
CL.III 700mA - 15V 700mA - 15V
White RAL 9003
LZ14706W
Light Grey RAL 7044
LZ14706L
Dark Grey RAL 7021
LZ14706D
Corten
LZ14706K
Complete the CODE
OPTIC
S
18°
M
28°
L
52°
E
11 X 37°
LED COLOUR
N
4000K
3
3000K
2
2700K

Lighting simulations

kura_top_x5_optic_e
kura_top_x5_optic_e
kura_top_x5_optic_l
kura_top_x5_optic_l
kura_top_x5_optic_m
kura_top_x5_optic_m
kura_top_x5_optic_s
kura_top_x5_optic_s
